ZXI™-10G
$9,178.92
This powerful, advanced cloning solution includes two 10GbE network connections and support to clone up to 16 M.2 NVMe SSDs with optional PCIe Expansion Modules. Maximize your productivity by utilizing the latest network technology to streamline your workflow and clone directly to or from a network repository or a NAS device. The ZXi™-10G also supports cloning from Thunderbolt™ storage enclosures utilizing two built-in Thunderbolt 4 ports.
The ZXi™-10G is the first hard drive duplicator on the market to include two 10GbE network connections, allowing you to streamline your workflow and clone directly to or from a network repository or a NAS device. The ZXi-10G also provides the ability, with an optional PCIe Expansion Module to clone M.2 NVMe SSDs. The ZXI-10G efficiently performs hard drive duplicating tasks including PC deployments, OS upgrades, content/application distribution and data back-up tasks.
- 2 10GbE network ports for fast cloning to/from a network repository or NAS
- Clone up to a total of 6 SATA/SAS-ready targets, add 4 targets with an optional expansion kit
- Clone M.2 NVMe SSDs using the optional PCIe Expansion Module
- Clone up to 8 Type-A USB 3.2 drives and 3 Type-C drives
- Two Thunderbolt™ 4/USB-C port available to clone to/from Thunderbolt storage enclosures
- Blazing fast hard drive duplicating at up to 29GB/min*
- Supports SATA, USB3 in the base unit, optional support for SAS drives is available
- Support for IDE, ZIF, mSATA, microSATA, eSATA drives and compact flash media is available with optional adapters
- Supports both mirror copy (100% bit for bit) and a “CleverCopy” mode that intelligently copies only data areas of the hard drive
- Safely sanitize drives with a wipe feature. Supports DoD 7 pass, Secure Erase and meets NIST 800-88 guidelines
Features
Hard Drive Duplication
The ZXi™-10G supports cloning 3.5″/2.5″ SATA hard drives,3.5″/2.5″ SAS (optional), USB enclosures and thumb drives. M.2 NVMe drives are supported with an optional PCIe Module. Optional adapters are available for 1.8″/2.5″/3.5″ IDE and IDE ZIF drives, eSATA, microSATA, mSATA and flash media. For information on which adapters suit your needs refer to our ZXi adapter guide.
M.2 NVMe Support
M.2 NVMe SSDs are supported with the optional 8-port PCIe Expansion Module. Supports cloning up to 16 M.2 NVMe SSDs using two modules. Click here for the PCIe Expansion Module datasheet.
Network Cloning
Allows network access (upload/download) to drive images and log files. Utilize the high-speed 10GbE connections to clone to/from a network repository or NAS solution and achieve transfer speeds of up to 30GB/min. Two 10GbE ports are available for use. A 2.5GbE port is available to minimize bottlenecks.
USB Cloning
Supports cloning to and from USB enclosures and thumb drives. 9 ports are available:
6 USB 3.2 Gen 1 (Type A)
2 USB 3.2 Gen 2 (Type A)
1 USB 3.2 Gen 2×2 (Type C)
6 USB 3.2 Gen 1 (Type A)
2 USB 3.2 Gen 2 (Type A)
1 USB 3.2 Gen 2×2 (Type C)
Multi-Target Cloning
Clone from 1 master to 5 SATA or 5 SAS (if SAS option is purchased) target drives, or clone from a ZXi-10G created image stored on an external USB enclosure or on a network repository to a total of 6 SATA/SAS target hard drives
Data Transfer Rate
The ZXi-10G duplicates hard drives at speeds up to 29GB/min*
Multiple Master/Source and Target Drives
Users can assign any drive stations as a master or target drive
4 Drive Expansion Kit
The optional expansion kit provides an additional 2 SAS/SATA and 2 SATA only targets for a total of 9 SATA (7 SAS) targets when cloning from a master hard drive or 10 SATA (8 SAS) targets from a ZXi-10G created image stored on a network repository or from a repository stored on an external USB enclosure connected to the ZXi-10G. Click here for a picture of the 4 Drive Expansion kit.
Wipe Feature
Choose from Secure Erase, DoD wipe, and custom pass settings. Complies with NIST 800-88 guidelines. User selectable option to verify wipe pass value during the wipe process.
Hash Verification Option
This optional feature allows the user to clone and verify the exact replication of the master drive. Features user-selectable SHA-1, SHA256 or MD5 algorithms
Multiple Cloning Modes
Supports Mirror (bit for bit copy) and CleverCopy (copies only data areas, skips blank sectors)
Audit Trail/Log Report
Detailed information about the cloning session is provided, and reports can be printed from a browser or via CLI. Report includes a digital signature for authentication purposes
Flat-Bed Design
The ZXi-10G features a flat-bed design with removable, field-replaceable drive stations. The drive stations provide drive power port protection.
Remote Operation
ZXi-10G allows you to control all operations from a remote computer using a web browser or Command Line Interface (CLI)
Cloning
Supports cloning from a ZXi-10G-created image stored on a USB enclosure connected via one of the ZXi-10G’s USB 3.0 ports, from a ZXi-10G-created image stored on a shared network drive location, or clone from a master/source hard drive
Multi-Session Capability
Allows users to perform multiple tasks including cloning wiping or hashing concurrently
Write-Protected Source
ZXi-10G drive stations or USB ports that are designated as a master by the user are automatically write-blocked to prevent any alteration to sensitive data on the source drive
Large Capacity Drives
The ZXi-10G provides support for today’s large capacity drives (>2TB)
Task Macro
Allows users to set specific tasks to be performed sequentially. For example, set task 1 to wipe, task 2 to clone, task 3 to hash.
File Systems
Supports all OS and file systems including Linux and Mac in Mirror mode. Supports FAT16/FAT32/NTFS and Linux (ext, ext2, ext3, ext4) in CleverCopy mode.
Removable Drive Stations
Provides fast, easy connection to a variety of hard drive types. Removable drive stations are field replaceable.
Blank Disk
Blank disk feature checks if the drive is blank
Drive “Time Out”
A user-selectable feature will set a specific “time-out” for drives connected to ZXi-10G. After a specified idle time the drive will automatically be put into standby mode, powering down the drives.
Advanced Administrative Functions”
Administrators can create/manage image repositories, manage network settings, create user profiles, save configurations, manage drive station assignments
Error Handling
A error granularity user-selectable setting provides more control over error handling of the master drive. Four cluster size settings are provided to determine the number of sectors to be skipped when a bad sector is found on the master drive. The ZXi-10G can also abort or skip bad sectors found on the master drive.
HPA/DCO
Clone or wipe HPA/DCO areas of the drive
Color Touch Screen Display
A vibrant display provides an intuitive and easy to use interface
Compact Footprint
The ZXi-10G takes up minimal real estate on the work bench at a size of 3.7″ X 19″ X 17.2″ (9.39cm X 48.26cm X 43.68cm) and weighs only 14lbs (6.4kg)
Specs
Power Requirements:
110V-240V, 7.5A-3.5A, 50-60Hz
Operating Temperature:
32-122F (0 to +50C)
Storage Temperature
-4 to 176F (-20 to +80C)
Relative Humidity:
Operating: 85% RH, non condensing. Storage: 95% RH, non-condensing
Net Weight:
14lbs (6.4 kg)
Dimensions:
17.2″ W X 19″ D X 3.7″ H (43.68cm X 48.26cm X 9.39cm)
Accessories
mSATA to SATA Adapter
mSATA to SATA adapter to clone mSATA type drives.
microSATA to SATA Adapter
microSATA to SATA adapter to clone microSATA drives.
eSATA Cable
Cable for eSATA hard drives to clone eSATA drives.
2.5″/3.5″ IDE to SATA Adapter
2.5/3.5″ IDE to SATA adapter to clone 2.5″ or 3.5″ IDE/PATA drives.
1.8″ IDE to SATA Adapter
1.8″ IDE to SATA adapter to clone 1.8″ IDE/PATA drives.
1.8″ ZIF to SATA Adapter
1.8″ ZIF to SATA adapter to clone 1.8″ ZIF drives.
USB Flash Card Reader
Used for cloning various flash media, including compact flash, SD cards.
SATA/SAS Data & Power Replacement Cable
SATA/SAS data & power replacement cable.
